Vertical Cylinder Fine Boring Machine

Get a Price/Quote

MOQ : 1 Piece

Vertical Cylinder Fine Boring Machine Specification

Cooling System
Integrated Coolant System

Drive
Belt Drive

Model No
ZII-VCB-1200

Machine Type
Vertical Boring

Features
Variable spindle speed, heavy-duty design, precise head travel

Motor Power
Spindle 1.5 Kw; Rapid 0.38 Kw

Production Capacity
Multiple cylinders per shift

Frequency
50 Hz

Operating Temperature
Ambient

Voltage
415 V

Lubricating System
Automatic Lubrication

Power Rating
1.5 Kw (Spindle), 0.38 Kw (Rapid Up/Down)

Frame Type
Heavy Duty Welded

Noise Level
Low

Accuracy
High Accuracy

Product Type
Vertical Cylinder Fine Boring Machine

Technology
Advanced Precision Boring

Power Source
Electric

Power
1.88 kW (Total Installed)

Dimension (L*W*H)
1900 x 1300 x 2440 mm

Weight (kg)
2400 kg

Color
Industrial Grey

Usage & Applications
Cylinder block boring for automotive, marine, and industrial engines

Material capability
Cast iron, steel

Spindle to column
360 mm

Application
Engine block boring

Approx weight
2400 Kg

Overall size
1900x1300x2440 mm

Rapid up/down power
0.5 Hp

Table traverse cross
75 mm

Head travel max
600 mm

Table size
1200x360 mm

Table traverse long
850 mm

Column type
Vertical heavy column

Spindle speed
50-500 rpm

Boring capacity
62-135 mm

Spindle to table max
1300 mm

Spindle feed
12-50 mm/min

Working Speed
Variable (50 - 500 rpm)

Operator panel
Simple manual controls

Vertical Cylinder Fine Boring Machine Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
1 Piece Per Week

Delivery Time
7 Days

About Vertical Cylinder Fine Boring Machine

Access venerable engineering performance with the ZII-VCB-1200 Vertical Cylinder Fine Boring Machine-a potent tool that offers precision, reliability, and superlative accuracy. Procure this specialized, heavy-duty column-type machine, ideal for automotive, marine, and industrial engine block machining. Experience variable spindle speed (50-500 rpm), impressive boring capacity (62-135 mm), and salient features like an integrated coolant system, automatic lubrication, and high-accuracy operation. The simple manual controls and electric-powered semi-automatic operation enable operators to procure superior results. Engineered for demanding applications, this is your gateway to high-efficiency production.

Unmatched Features and Competitive Edge

The ZII-VCB-1200 Vertical Cylinder Fine Boring Machine is fortified with advanced precision boring technology and a robust welded frame for durability. Features like variable speed, potent head travel, and precise spindle feed enhance operational flexibility. Its integrated coolant and automatic lubrication systems maintain peak performance. Primary competitive advantages include heavy-duty construction, minimal noise, and high production capacity, elevating machining standards for demanding engine block applications. Rely on this machine for superior results and extended service life.

FOB Port, Secure Shipping & Payment Flexibility

ZII-VCB-1200 Vertical Cylinder Fine Boring Machine is dispatched safely from major Indian FOB ports, ensuring secure shipping and minimized expenditure every transaction. Our flexible payment terms adapt to your procurement needs, providing convenience for manufacturers, importers, and suppliers. With a reliable supply ability, we guarantee timely delivery and streamlined dispatching workflows, so production requirements are efficiently met without compromising on quality or lead time.

FAQ's of ZII-VCB-1200 Vertical Cylinder Fine Boring Machine:

Q: How does the ZII-VCB-1200 Vertical Cylinder Fine Boring Machine benefit engine block machining?

A: The ZII-VCB-1200 delivers high accuracy, variable spindle speed, and precise head travel, ensuring optimal results for automotive, marine, and industrial engine block machining. Its potent design enables consistent and high-quality boring for multiple cylinders.

Q: What are the primary features that make this machine special?

A: Key features include a variable speed spindle, heavy-duty vertical column, integrated coolant system, automatic lubrication, and a robust welded frame, making it a superlative choice for precision and productivity.

Q: Where is the ZII-VCB-1200 typically dispatched from, and how is shipping managed?

A: The machine is securely shipped from major Indian FOB ports, with meticulous packing to ensure safe delivery and minimized shipping expenditure.

Q: What payment terms and supply abilities are available for procurement?

A: Flexible payment options are provided based on customer requirements, and the manufacturer maintains strong supply ability, ensuring timely availability and efficient dispatching.

Q: How is the operator interface designed for ease of use?

A: The operator panel features simple manual controls combined with electrical levers, allowing intuitive operation and facilitating accurate, consistent results even for less-experienced users.
