Hydraulic Press (Power Operated)

Get a Price/Quote

MOQ : 1 Piece

Hydraulic Press (Power Operated) Specification

Noise Level
Below 70 dB

Frequency
50 Hz

Machine Type
Hydraulic Press

Cooling System
Oil Cooling

Features
Heavy Duty Frame, Low Maintenance, Safety Interlock, Easy Operation

Motor Power
5 HP

Power Rating
3.7 kW

Lubricating System
Centralized Lubrication

Drive
Hydraulic

Accuracy
0.1 mm

Model No
ZII-HPP-001

Operating Temperature
5C to 50C

Production Capacity
30 Pieces/Day

Voltage
415 V

Frame Type
H-Frame

Product Type
Hydraulic Press (Power Operated)

Technology
Hydraulic

Power Source
Electric

Operating Type
Automatic

Power
5 HP

Pressure
100 Ton

Surface Treatment
Paint Coated

Dimension (L*W*H)
1500 mm x 800 mm x 2000 mm

Weight (kg)
1200 kg

Color
Blue / Silver

Usage & Applications
Metal Forming, Bending, Punching, Assembly Operations

Ram Size
250 mm diameter

Cycle Time
Approx. 30 seconds

Hydraulic Oil Type
ISO VG 68

Table Size
800 mm x 500 mm

Maximum Stroke
300 mm

Safety Features
Overload Protection, Emergency Stop Button

Application Material
Mild Steel, Stainless Steel, Aluminium

Oil Tank Capacity
80 L

Hydraulic Press (Power Operated) Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
1 Piece Per Week

Delivery Time
7 Days

About Hydraulic Press (Power Operated)

Tones	Job Rest Bed Size	Distance Between Ram and Bed		Ram Stroke
		Minimum	Maximum
5	500 mm x 125 mm	75 mm	600 mm	100 mm
10	600 mm x 150 mm	75 mm	600 mm	125 mm
15	650 mm x 150 mm	75 mm	600 mm	150 mm
25	850 mm x 300 mm	175 mm	900 mm	175 mm
40	950 mm x 350 mm	175 mm	900 mm	190 mm
50	1000 mm x 400 mm	175 mm	950 mm	200 mm
60	1050 mm x 450 mm	175 mm	950 mm	215 mm
75	1125 mm x 500 mm	175 mm	950 mm	225 mm
100	1250 mm x 600 mm	175 mm	950 mm	240 mm
150	1300 mm x 625 mm	175 mm	1000 mm	250 mm
200	1325 mm x 625 mm	175 mm	1000 mm	275 mm
250	1350 mm x 650 mm	175 mm	1000 mm	300 mm
300	1400 mm x 650 mm	175 mm	1000 mm	325 mm
500	1425 mm x 675 mm	175 mm	1000 mm	375 mm

Get an unmissable Discount and Hot deal on the ZII-HPP-001 Hydraulic Press (Power Operated), a crowning achievement in metalworking technology. Delivering a transcendent hydraulic force of 100 Tons and pristine accuracy of 0.1 mm, this press boasts an 800 mm x 500 mm table and a robust H-Frame for heavy-duty applications. Featuring sophisticated safety systems, centralized lubrication, and rapid 30-second cycle times, it is engineered for bending, punching, and assembly operations on stainless steel, mild steel, and aluminium. Experience pristine efficiency and crowning reliability in every operation!

Unmatched Competitive Edge & Industrial Versatility

ZII-HPP-001 Hydraulic Press offers a crowning set of advantages for demanding industries, including its transcendent accuracy, low maintenance, and heavy-duty build. Ideal for plant applications in fabrication, assembly, and metal forming, it flawlessly processes mild steel, stainless steel, and aluminium. The machine's pristine performance is enhanced by a powerful 5 HP motor, oil cooling system, and overload protection, establishing it as a go-to solution for precise, high-volume hydraulic pressing tasks.

Streamlined Packaging & Global Premium Delivery

Experience seamless packaging with the ZII-HPP-001 Hydraulic Press-every unit is securely packed for international delivery, ensuring it arrives in pristine condition. We offer prompt delivery times tailored to your project's needs, with premium export markets including Europe, Asia, Africa, and the Middle East. Samples are available for a nominal charge, letting you assess quality before investing. Choose us for a refined solution-from inquiry through delivery, your satisfaction is our priority.

FAQ's of ZII-HPP-001 Hydraulic Press (Power Operated):

Q: How does the ZII-HPP-001 Hydraulic Press ensure operational safety?

A: The press features integrated overload protection, an emergency stop button, and a safety interlock system, providing optimal safety during all hydraulic operations.

Q: What types of materials can this hydraulic press process?

A: It is engineered for use with a range of application materials, such as mild steel, stainless steel, and aluminium, making it ideal for various metal forming processes.

Q: Where can the ZII-HPP-001 be applied within a manufacturing plant?

A: This hydraulic press excels in metal forming, bending, punching, and assembly operations, making it suitable for automotive, fabrication, and industrial manufacturing sectors.

Q: What is the process for ordering a sample of the ZII-HPP-001 Hydraulic Press?

A: You can request a sample for a nominal charge. Contact our sales team, and we'll guide you through the premium packaging and shipping procedures.

Q: What are the main benefits of using this press for production operations?

A: The press delivers transcendent performance with pristine accuracy and high efficiency, while the powerful hydraulic system and automated features support high production capacity and minimal maintenance costs.
